A high-quality automated tablet presses with automatic weight control. Suitable for a wide range of applications in R&D, Pilot & production scale. Elite Press is a fully GMP compliant tablet press by choice of material and design. Proprietary-wear resistance coating on the turret sections and the integration of hardened steel die-plate provide for long life before repair. High-torque motor, direct drive and high- strength frame design provides for “best in class” compression under real-life operational loads.
High Production (Double Rotary with a compact Footprint)
Key Features:
- Compact Footprint
- Motorized Penetration Control
Output:
|
No. of Stations & Tooling |
51 D |
61 B |
75 BB |
|
Output/hr (Single Layer) |
459,000 |
549,000 |
675,000 |
|
Output/hr (Bi-Layer) |
153,000 |
183,000 |
275,000 |
|
Pre Compression Force |
10 Ton/100 kN |
||
|
Main Compression Force |
10 Ton/100 kN |
||
Available Variant –
High Production (Mono Layer & Effervescent)
Key Features:
- Good Sample & Reject Tablet Collection
- High Torque Reduction Gearbox
- Online Magnesium Spray & Liquid Paraffin Spray (Optional)
Output:
|
No. of Stations & Tooling |
32 D |
38 B |
45 BB |
|
Output/hr (Single Layer) |
134,400 |
159,400 |
189,000 |
|
Tablet Diameter (Single Tip) |
5 to 24 |
5 to 16 |
5 to 13 |
|
Pre Compression Force |
10 Ton/100 kN |
||
|
Main Compression Force |
10 Ton/100 kN |
||
Available Variant –
Medium Production (Double Rotary Layer)
Key Features:
- Auto sampling of First Layer Tablet during Bi-Layer Tabletting
- Precise Punch Tracking with Encoder
- Tool Safe Overload Safety
Output:
|
No. of Stations & Tooling |
29 D |
37 B |
45 BB |
|
Output/hr (Single Layer) |
174,000 |
222,000 |
270,000 |
|
Output/hr (Bi-Layer) |
52,000 |
66,000 |
81,000 |
|
Pre Compression Force |
3 Ton/30 kN |
||
|
Main Compression Force |
10 Ton/100 kN | 6.5 Ton/65 kN |
||
Available Variant –
R&D Production (Pilot Single Layer)
Key Features:
- Tool-less Hoper Fitment
- Turret with Lower Punch Seal
- Heavy Duty & Study Construction
Output:
|
No. of Stations & Tooling |
8 D |
10 B |
12 BB |
5D + 5B |
|
Output/hr (Single Layer) |
14,400 |
18,000 |
21,600 |
9,000 |
|
Pre Compression Force |
5 Ton/50 kN |
|||
|
Main Compression Force |
5 Ton/50 kN |
|||
Available Variant –
R&D Production (Pilot Bi-Layer)
Key Features:
- Single Paddle Force Feeder
- Direct Drive to the Turret
- Double Walled CAM Design
Output:
|
No. of Stations & Tooling |
9 D |
11 B |
13 BB |
5D + 5B |
|
Output/hr (Single Layer) |
16,200 |
19,200 |
23,400 |
9,000 |
|
Pre Compression Force |
3 Ton/30 kN |
|||
|
Main Compression Force |
5 Ton/50 kN |
|||
Available Variant –
